Twyford Sola washbasin tap, deck-mounted, single-lever thermostatic mixer

My list (0)

Articles

Click on the icon with the 3 dots to have more options for each item.

Art. no.	SF1133CP
Colour / surface	chrome / glossy
Mixer	with thermostatic mixer

Technical data

Operating pressure	0.5–10 bar	Operating pressure 0.5–10 bar
Water temperature max.	85 °C	Water temperature max. 85 °C
Flow rate at 300 kPa / 3 bar	5.1 l/min	Flow rate at 300 kPa / 3 bar 5.1 l/min
Minimum flow pressure	0.5 bar	Minimum flow pressure 0.5 bar

Calculated flow rate	0.08 l/s	Calculated flow rate 0.08 l/s
Product material	Brass / plastic	Product material Brass / plastic

Operating pressure	0.5–10 bar	Operating pressure 0.5–10 bar
Water temperature max.	85 °C	Water temperature max. 85 °C
Flow rate at 300 kPa / 3 bar	5.1 l/min	Flow rate at 300 kPa / 3 bar 5.1 l/min
Minimum flow pressure	0.5 bar	Minimum flow pressure 0.5 bar
Calculated flow rate	0.08 l/s	Calculated flow rate 0.08 l/s
Product material	Brass / plastic	Product material Brass / plastic

Application purposes

Click on an application purpose to search more products

For public and semipublic areas For clinical applications For installation in washbasins or washtops

Characteristics

Click on a characteristic to search more products

Single-lever mixer With thermostatic mixer Volume flow control via tap aerator With collar

Documents

Document type	Documents	Language
Installation instructions		EN

Other products

Sola

Taps

Twyford Sola washbasin tap, deck-mounted, single-lever thermostatic mixer, lever extended

SF1120CP

Sola

Taps

Twyford Sola washbasin tap, deck-mounted, single-lever thermostatic mixer, removable spout

SF1134CP

Sola

Taps

Twyford Sola washbasin tap, deck-mounted, single-lever thermostatic mixer, inlet reinforced braided hoses

SF1138CP

Sola

Taps

Twyford Sola washbasin tap, deck-mounted, single-lever thermostatic mixer, removable spout, copper inlet pipes

SF1139CP

Sola

Taps

Twyford Sola washbasin tap, deck-mounted, single-lever thermostatic mixer, lever extended, copper inlet pipes

SF1140CP

Sola

Taps

Twyford Sola set of washbasin taps, deck-mounted, single-lever mixer, lever actuation

SF2401CP

Sola

Taps

Twyford Sola set of washbasin taps, deck-mounted, single-lever mixer, tall design, lever actuation

SF2403CP

Sola

Taps

Twyford Sola washbasin tap, deck-mounted, single-lever mixer

SF5357CP

Spare parts

Sola washbasin taps, wall-mounted, single-lever thermostatic mixer

2016 -

#	Art. no.	Description
1	SF0136XX	SURGEONS MIXER TMV CARTRIDGE
2	SF0131XX	SURGEONS MIXER FILTER- CHECK VALVE HOUSI
2.1	SF0140CP	SURGEONS MIXER TAP BODY END CAP

Open detail page

4 Articles
