Twyford Sola washbasin tap wall-mounted, battery operation, thermostatic mixer, removable spout
My list (0)
Technical data
Operating voltage 6 V DC |
Operating pressure 0.5–10 bar |
Test pressure, water max. 8 bar |
Test pressure, air / inert gas max. 3 bar |
Ambient temperature 1–40 °C |
Storage temperature 5–70 °C |
Operating temperature, water max. 85 °C |
Operating temperature, water, short-term max. 85 °C |
Flow rate at 3 bar 5.1 l/min |
Flow rate at 3 bar 0.08 l/s |
Minimum flow pressure 0.5 bar |
Calculated flow rate 0.08 l/s |
Interval flush, factory setting 24 h |
Interval flush time, factory setting 60 s |
Product material Brass / plastic |
